1. LIFTING THE MACHINE
A. The machine should be lifted using the front of the handle and the
handgrip on the rear handle tower.
2. INSTRUMENT PANEL COMPONENTS
The instrument panel components are identified as follows:
A. ON/OFF Brush Control
B. ON/OFF Solution Control
C. ON/OFF Vacuum Control
D. Fuse Holder
E. Electrical Supply Cord
3. MACHINE COMPONENTS
The machine components are identified as follows:
A. Auxiliary Solution Connection
B. Solution Flow Control Valve
C. Head Pressure Adjustment Bolt
D. Transport Wheel Engagement Lever
E. Handle Position Locking Device
F. Solution Level Sight Gauge
G. Auxiliary Vacuum Connection
