ITEM NO.
QTY.
PART NO.
DESCRIPTION
1 1
E88676
Tank - Recovery
2 1
E88714
Recovery Tank Window Lower
3 1
E88678
Recovery Tank Upper Window Cover
4 1
E88798
Gasket, Lid, Upper to Lower, Vacuum 18/8" Neoprene
5 1
E88799
Gasket, Lid, Upper to Lower Solution, 1/8" Neoprene
6 1
E88797
Gasket, Lid to Tank, 1/4" Foam
7 1
E88707
Hinge Mount Plate
8 1
E88685
Hinge Door
9 1
E88748
Hinge Spring
10 1
E88749
DD2 Hinge Pin
11 1
E88631
Gasket - Hinge Door
12 13
E88716
Screw, #10 x 3/8", Thread Forming Plastic, Pan Head, Zinc
13 2
E83879
Washer, Flat M5 x 11 x 1, Zinc
14 1
E88718
Float Ball 37mm
15 2
E88713
Recovery Tank Seal
16 1
E88800
Hose Cuff, Elbow, Recovery Tank Lid Inlet
17 1
E88890
Cable Tie 8x0.14 Plastic
To Next Page
