CONNECTIONS
Be sure to check the model and style number of a relay before connecting and energizing the relay.
Incorrect wiring may result in damage to the relay. Except where noted, connections should be made with
wire no smaller than 14 AWG.
Typical internal connections are shown in Figures 4-13 through 4-15. Typical ac connections are shown in
Figure 4-16. Typi
cal dc connections are shown in Figure 4-17.
Figure 4-13. BE1-27 Internal Connections
4-14 BE1-27/59 Installation 9170600990 Rev H
