Basler BIP2 c Series User Manual

Installation Guide
10 Basler IP Fixed Box Cameras
9. Connect an Ethernet cable to the RJ-45 connector on the camera and to
your network switch as shown below.
10. Plug in or switch on the power supply.
11. Go on to Section 2.2 on page 11.
Network Switch
Ethernet
Patch
Cable
Gnd
+ DC In
Weidmüller Plug
Pin 1
