5-2 9469300994
Voltage and Current Sensing DGC-2020HD
Table 5-3. Generator Current Sensing Terminals
Terminal
Description
1 (IA+)
A-phase generator current sensing input
2 (IA–)
3 (IB+)
B-phase generator current sensing input
4 (IB–)
5 (IC+)
C-phase generator current sensing input
6 (IC–)
Table 5-4. Bus Current Sensing Terminals
Terminal
Description
7 (AUX I1+)
User-programmable current sensing input 1
8 (AUX I1–)
9 (AUX I2+)
User-programmable current sensing input 2
10 (AUX I2–)
11 (AUX I3+)
User-programmable current sensing input 3
12 (AUX I3–)
13 (AUX I4+)
User-programmable current sensing input 4
14 (AUX I4–)
Caution
Generator current sensing terminals 2 (IA–), 4 (IB–), and 6 (IC–) and
user-programmable current sensing terminals 8 (AUX I1–), 10 (AUX
I2–), 12 (AUX I3–), and 14 (AUX I4–) must be terminated to ground for
proper operation.
Note
Unused current sensing inputs should be shorted to minimize noise
pickup.
