AW00118508000 Specifications, Requirements, and Precautions
Basler racer Camera Link 7
Specification raL12288-66km
Resolution 12288 pixels
max. 12280 pixels available with 1X10 tap geometry
Sensor Type Awaiba DR-12k-3.5
Monochrome Linear CMOS
Effective Sensor Diagonal 43.01 mm
Pixel Size 3.5 µm x 3.5 µm
Max Line Rate 66 kHz
Min Line Rate No minimum when a hardware trigger signal is used
100 Hz when a hardware trigger signal is not used
Mono/Color Mono
Sensor Bit Depth 12 bit
Data Output Type Camera Link base, medium or full configuration
Connectors One 6-pin Hirose micro-miniature receptacle
Two Camera Link 26-pin SDR connectors
(also known as Mini Camera Link connectors)
Camera Link Pixel Clock
Speed (Nominal)
32.5 MHz, 48 MHz, 65 MHz, 83.5 MHz (selectable; for the difference between
nominal and actual values, see Section 8.1 on page 100)
Camera Link Tap
Geometry
1X, 1X2, 1X4, 1X8, 1X10
Pixel Formats Mono 8
Mono 10
Mono 12
Synchronization Via hardware trigger signal, via software trigger signal or free run
Exposure Time Control Programmable via the camera API
Camera Power
Requirements
+12 VDC (-10 %) to +24 VDC (+5 %), < 1 % ripple, supplied via the camera’s
6-pin connector.
Power Consumption
(typical, at 12 VDC)
6.5 W
I/O Lines 4 input lines (CC1 to CC4) and 1 output line (via Camera Link spare bit)
Lens Adapter Universal camera front, suitable for lens mount adapters with the following lens
mounts: F-mount, M42x0.75-mount (FBD 16 mm), M42x1.0-mount (FBD 16 mm),
M42x1.0-mount (FBD 45.56 mm), M58x0.75-mount (FBD 20 mm).
Lens adapter must be ordered separately as an accessory. See Section 1.7.4 on
page 17 for information about selecting a suitable lens adapter for your camera.
Table 3: General Specifications - 12k Mono Cameras
