Basler raL12288-66km - Lens Adapter Dimensions

AW00118508000 Specifications, Requirements, and Precautions
Basler racer Camera Link 14
1.7.3 Lens Adapter Dimensions
Fig. 5: C-mount Adapter on a racer Camera Link Camera; Dimensions in mm
Fig. 6: F-Mount Adapter on a racer Camera Link Camera; Dimensions in mm
33.77
Photosensitive
Surface of the
Sensor
3
Not to Scale
40.07
ø53
ø51.2
5.5
8.41
17.526
48.48
56
62
ø30 ± 0.05
46.5
Photosensitive
Surface of the
Sensor
5.5
Not to Scale
3
33.77
40.07
37.5
77.57
ø59
56
62
ø51.5 ± 0.05
