battistella VULCANO - Specifications

Vulcano 9 2016
INSTRUCTIONS AND MAINTENANCE
VULCANO
Read the directions carefully before operating.
1. SPECIFICATIONS
MODEL: VULCANO VULCANO
MAXI
VULCANO
RECTANGULAR
POWER SUPPLY: 230 V - 50 Hz 230 V - 50 Hz 230 V - 50 Hz
TOTAL INSTALLED POWER: 3173 W 3373 W 3830 W
IRON POWER: 800 W 800 W 800 W
BOARD POWER: 600 W 800 W 1200 W
VACUUM POWER: 73 W 73 W 130 W
BOILER POWER: 1700 W 1700 W 1700 W
ARM POWER (optional): 150 W 150 W 150 W
BOILER CAPACITY: 3,8 L 3,8 L 3,8 L.
IRONING ENDURANCE:
about 4 hours about 4 hours about 4 hours
OPERATING STEAM PRESSURE: 2,8 BAR 2,8 BAR 2,8 BAR
MAXIMUM PRESSURE: 5 BAR 5 BAR 5 BAR
WEIGHT: 39 kg. 42 kg. 44 kg.
OVERALL DIMENSIONS: 140x41x98 h. cm 147x48x98 h. cm 145x58x98 h. cm
MADE IN ITALY
Fig. 1
