Vulcano 10 2016
2. IMPORTANT
Before installing VULCANO, it is necessary to set up a protected electrical socket
suitable to its power.
This ironing board is not suitable for people (children included) with physical or mental
handicaps or inexperienced persons, unless they are instructed by a person who takes the
responsibility for their safety. Children must not play with the ironing board.
3. OPENING OF PACKAGE
1. Open the box containing VULCANO (ALTO ), take out the manual of instructions
and read it carefully.
2. Remove VULCANO from the box, insert the cable support deep into the special hole
(fig. 1).
3. Fix the spring to the support hook, paying attention in order to avoid entwining
(fig. 1).
4. Place the iron on the rubber iron rest supplied with the machine (fig. 1).
4. CONNECTION AND STARTING
With VULCANO switched off and disconnected
plug:
1. Unscrew the safetyy valve plug (fig. 1) and fill
the boiler with water to the desired level by
using a funnel, paying attention not to overfill
it. Take the plug by the plastic part and screw
it again: do not tighten too much or its gasket
might get ruined (see section 7). N.B. make
sure the exhaust tap of the boiler is
closed (fig. 1).
2. Insert the plug into a 230 V 16 A socket.
3. Switch on the main switch and the boiler (fig.
2 A e B) and set board thermostat on 80/90°
(fig. 2 G), when the lamp F switches off the
board has reached the preset temperature.
Five minutes later switch on the iron (fig. 2 C)
and adjust the thermostat (fig. 3).
4. Wait for the boiler lamp to switch off (fig. 2 D). Seize the iron by cork handle and
press the red micro-switch for 4 or 5 times (fig. 4), so that steam comes out. It is
important to make sure it is a saturated steam (by pressing the micro switch with
the iron pointed downwards). You can adjust steam flux by turning the knob placed
on the solenoid valve (fig. 1). Now everything is ready for ironing. During ironing
operation, the boiler lamp switches on and off (fig. 2 D).
