SHANGHAI BAUDCOM COMMUNICATION DEVICE CO.,LTD
Website : www.baudcom.com.cn Tel: +86 21 37709251 Email: info@baudcom.com.cn Skyper: robert.luo905 Page 15
If you want to delete one connection, please select the wan
connection you want to delete and then check “Delete” option.
Enable or Disable the WAN Connection you have choosed.
Route/Bridge. The device works on route mode with this WAN
connection.
If you select Route WAN Connection,the NAT option is default
enable.If you select Bridge WAN connection,the NAT option is
default disable. Checked indicates the NAT Function is enabled.
Service mode indicates what the wan connection is used for.
There are INTERET 、TR069、Other and Voip for choosing.
Checked indicates the packets are transmitted by the PON port
take VLAN tag. Unchecked indicates the packets are transmitted
by the PON port don’t take VLAN tag.
Input the VLAN ID you want to set. Range is 0~4094. Input 0
means don’t use any VLAN.
Input the VLAN ID you want to set,according to the IPTV
Confiuration.This option default value is -1,means no use.
Select VLAN priority you want to set. Range is 0~7.
Checked the LAN Port indicates that lan interface would act with
this wan connection Route or Bridge.
Checked the SSID Port indicates that lan interface would act with
this wan connection route or bridge.
Max transfer unit. Default Value (in Byte):
1500(static/DHCP) or 1492(PPPoE).
The PPP Link maintenance time. This parameter value default is
60S.
Continous or Connect on Demand
This option is not required generally, but if the PPPoE Server
checks the option, you should input according to ISP.
