Baudcom BD-ONU-802RWT-H User Manual

SHANGHAI BAUDCOM COMMUNICATION DEVICE CO.,LTD
Website : www.baudcom.com.cn Tel: +86 21 37709251 Email: info@baudcom.com.cn Skyper: robert.luo905 Page 3
RF output level: 78dBuV
AGC range: 0~-15dBm
MER: ≥32dB@-15dBm
Wireless
Compliant with IEEE802.11b/g/n,
Operating frequency: 2.400-2.4835GHz
Support MIMO, Rate up to 300Mbps,
2T2R,2 external antenna 5dBi,
Support: multiple SSID
Channel: Auto
Modulation type: DSSS, CCK and OFDM
Encoding scheme: BPSK, QPSK, 16QAM and 64QAM
Push-Button
3,For Function of Reset、WLAN、WPS
Operating Condition
Temperature: 0℃~+50℃
Humidity: 10%～90%（non-condensing）
Storing Condition
Temperature: -30℃~+60℃
Humidity: 10%~90%（non-condensing）
Power Supply
DC 12V/1A
Power Consumption
≤6W
Dimension
155mm×92mm×34mm（L×W×H）
Net Weight
≤0.24Kg
Table 1: Technical parameters
1.4 Application chart
Figure 1-2: Application chart
