20
GAS REQUIREMENTS
Burners Oven Grill
Nominal rate kW 2,40 2,40
Reduced rate kW 0,70 1,60
Ø injector
LPG - G30 28..30mbar G31 37mbar mm 0,73 0,73
Natural Gas - G20 20mbar mm 1,15H 1,15
Ø by-pass:
G30 28..30mbar G31 37mbar mm 0,40 0,70
G20 20mbar mm Adjusted Adjusted
Air adjustment
G30 28..30mbar G31 37mbar mm 2,5 ------
G20 20mbar mm 2,5 ------
GAS CONNECTION – See Page 22 (Fig. 1 to 6).
PLEASE NOTE THAT THIS APPLIANCE SHOULD BE
FITTED BY A QUALIFIED CORGI REGISTERED
INSTALLER
The gas supply must be connected by an approved flexible stainless steel
Plug-in hose (Fig 1) and an extension of the appliance gas ramp (Fig. 2). The
flexible Plug-in hose must be installed so that it does not touch any surface
that exceeds 70°C. The appliance is supplied for use with Natural Gas, if it is
to be adapted for LPG the appliance must first be isolated from the electricity
and gas supplies. Open the oven door fully and proceed as follows: -
Oven Burner
• Remove the oven burner shield from inside the oven and remove the
burner (Fig. 3).
• Replace the injector with the one suitable for LPG to be used as listed
in the table above. It is recommended that the appropriate thread
sealant be used, always check for gas soundness after assembly.
