Reversing the doors of your appliance
The doors of your fridge freezer can be set to open from the left or the
right. If you want the doors to be hinged on the left hand side and
opening from the right hand side, you will need to follow the door
reversal process.
IMPORTANT: If required, the doors should be reversed PRIOR
to installing the appliance into the housing unit.
21
Caution! After unscrewing any of the fixing
hinges, hold the door to prevent it from falling
and causing damage.
Any parts that you remove from the appliance whilst
reversing the door, should be retained for later use.
1) Top hinge screws
2) Top hinge
3) Middle hinge
screws
4) Middle hinge
5) Lower hinge pin
6) Right lower hinge
receiver
7) Left lower hinge
receiver
