Fig 20
720mm models
Installation under a worktop
without housing unit.
720mm models
Installation under a worktop
unit with internal height of
less than 710mm.
min
580mm
min
580mm
720mm
558-564mm
600mm
720mm
runners
runners
20mm
20mm
720mm
720mm
95mm
55mm
35mm
