Technical Specifications
If the appliance does not work, inform
Technical Service of the kind of problem you
are experiencing and give the:
1 Serial Number (S-No)
2 Model of Appliance (Mod.),
which you will find engraved on the identifica-
tion plate. This plate is located on the bottom
of the oven and can be seen when opening the
door.
Installation
This information is exclusively for the installer
who is responsible for assembly and electrical
connection. If you install the oven yourself, the
manufacturer will not accept liability for possi-
ble damage.
Please refer to electrical safety instructions
on page 3 of this manual before installation.
• To unpack the oven, pull on the tab located
at the bottom of the box and hold it by the
side handles, never by the oven door handle.
• The installation instructions must be
adhered to strictly. If not, the oven’s venti-
lation circuit may become blocked, causing
high temperatures that could damage the
kitchen unit and the appliance itself.
• The opening in the kitchen unit must be that
indicated in Figures 8, 9 and 10, depending
on the type of installation. The minimum
size of the unit base must be 580 mm.
• The rear of the unit, corresponding to the
shaded area (A) in Figure 11 must have
nothing projecting from it (unit reinforce-
ment, pipes, sockets, etc.).
Prior to Installation
• The unit material, including covering materi-
als and glue must be able to withstand tem-
peratures of 120 ºC.
The installer must ensure that:
• The mains power voltage and frequency cor-
respond to what is marked on the identifi-
cation plate.
• The domestic wiring system can withstand
the maximum power marked on the identifi-
cation plate.
• After connecting the power, check that all
electrical parts of the oven are working cor-
rectly.
• Disconnection from the electrical supply
must be allowed after the oven is in the
installed position.
After connecting the power to the oven:
1 Position the oven inside the unit and ensure
that the power cable is not trapped or in
contact with parts of the oven that heat up.
2 Position the oven at the centre of the unit
so that there is a separation of at least 5
mm between the oven and the adjacent
units. Figures 13 and 14.
3 Anchor the oven to the unit with the two
screws supplied, screwing them into the
unit through the two holes that can be seen
when the door is open.
Electrical Connection
Oven Installation
