29
TO INSTALL THE DÉCOR DOOR (Fasçia)
NOTE: Before installing your décor door, you will have to decide
whether you want it to open to the LEFT or to the RIGHT.
1. Using the supplied template, mark the points where you are going to
drill the holes to attach the décor door.
Taking a drill, make two holes of 2mm diameter and one hole of 3.5mm
diameter in the places illustrated below. Then attach the hinges with
screws. Shown below is the version opening to the RIGHT
. Note: the
higher hinge is on the left (below) while the lower is on the right.
