Baumatic F90.2BL - Specifications of Your Cooker Hood; Btc6720 Bl;Ss;W

8
Specifications of your cooker hood
BTC6720BL/SS/W
PRODUCT
DIMENSIONS
Height: 645* mm –
1025 mm
Width: 600 mm
Depth: 500 mm
DIMENSIONS OF
CHIMNEY SECTION:
170 mm x 221 mm
Your stainless steel cooker hood is fitted with:
o Integrated tangential motor
o Push button control operation
o 3 Speeds
o 2 Washable metallic grease filters
o 2 lights
Extraction capacity:
750 m³/hr
Noise level min/max:
61 / 65 / 68 dB
MODEL NUMBER
CARBON FILTER REQUIRED
BTC6720BL/SS/W S1
* If you are using the appliance in recirculation mode, then PLEASE
NOTE that some of the vent in the upper chimney section must be
exposed. You will have to take this into account when calculating the
minimum height of the cooker hood when installed.
