Using the hob top
The following symbols will appear on the control panel, next to each
control knob:
Black circle: gas off
Large flame: maximum setting
Small flame: minimum setting
o The minimum setting is at the end of the anti-clockwise rotation
of the control knob.
o All operation positions must be selected between the maximum
and minimum positions.
o Never select a knob position between the maximum and off
position.
Automatic electric ignition with flame failure safety device
To ignite a burner:
o Press in the control knob of the burner that you wish to light and
turn it clockwise to the maximum position.
o If you keep the control knob depressed, the automatic ignition
for the burner will operate.
o IMPORTANT: Once the burner has lit, continue to keep the
control knob held down for a further 10 seconds. Otherwise the
safety cut off will operate and block the flow of gas.
o In case of power failure, the burners can be lit by carefully using
a match.
17
