Installing your cooker hood
o We recommend that at least two people install this hood.
IMPORTANT: THE MAINS SUPPLY THAT YOUR COOKER HOOD IS
CONNECTED TO, MUST NOT BE SWITCHED ON UNTIL AFTER THE
REST OF THE INSTALLATION PROCESS HAS BEEN COMPLETED.
1) Reach inside of the appliance, remove the tape that secures the
power cable to the framework and release it.
2) Turn the hood upside down, so that the bulbs are facing upwards.
o Open the cover screen.
o Remove the grease filter by pulling down on the latch and pulling it
away from the hood.
3) From inside of the motor housing,
undo the four screws that hold the
framework in position.
4) As shown in the picture, remove
the four screws which hold the inner
chimney section to the upper plate.
5) Dislocate the cooker hood from the framework by lifting the hood
clear of the framework.
18
