Baumatic QF9SS - Installation Instructions - Attaching the Hood

15
-------------------------------------------------------------------------------------------
-------------------------------------------------------------------------------------------
6) (EXTRACTION FUNCTION ONLY) Connect the coupling to the top of the
cooker hood (see below). Then connect the discharge pipe to the coupling as
shown below. Remember that your ducting will have to have to match the
specifications shown in the notes on Extraction / Air Purifier Modes on p.18.
INSTALLATION INSTRUCTIONS – Attachin
g
the Hood
