5) Push down the left hand collar of the coupling and then insert
the water tube as far as it will go into the coupling. When it is
securely in position, release the left hand collar.
Replacing the fridge door
1) Insert the bottom of the fridge door into the bottom hinge,
making sure that the hinge pin has been inserted into the hole
in the bottom of the fridge door.
2) Insert the back of the top hinge in the groove on the top of the
cabinet. Close the door fully against the cabinet, and then
make sure that the top hinge pin is fitted securely into the hole
on top of the freezer door.
3) Reconnect the harness wires and then turn the hinge fastener
clockwise. IMPORTANT: You should make sure that the hinge
fastener is securely tightened as far as it will go.
34
