4.2.1. Indicate optional column of figures in upper line „t“ (74h)
This command is utilized to indicate a 5-digit number in the upper line of the display. The numerical column is
indicated less dot respectively comma. Preceding zeroes as well as both arrows are suppressed. The bottom
line still indicates the actual value.
The numerals are indicated in the display until any command except „t“, „u“ or „R“ is received. The number will
be retained after power failure.
Example: (Column of figures = 054321)
SOH Adr Cmd Column of figures = 054321 EOT CRC
Transmission
01h 20h 74h
30h 35h 34h 33h 32h 31h
04h C6h
SOH Adr Cmd Column of figures = 054321 EOT CRC
Response
01h 20h 74h
30h 35h 34h 33h 32h 31h
04h C6h
4.2.2. Indicate optional column of figures in bottom line „u“ (75h)
The command utilized to indicate a 5-digit column of figures in the bottom line of the display. The number is in-
dicated less dot respectively comma. Preceding zeroes as well as both arrows are suppressed. The upper line
still indicates actual target or the column of figures.
The column is indicated until any optional command except „t“, „u“ or „R“ is received by the interface. The num-
ber will be retained after power failure.
Example: (Column of figures = 012345)
SOH Adr Cmd Column of figures = 012345 EOT CRC
Transmission
01h 20h 75h
30h 31h 32h 33h 34h 35h
04h B6h
SOH Adr Cmd Column of figures = 012345 EOT CRC
Response
01h 20h 75h
30h 31h 32h 33h 34h 35h
04h B6h
Note:
Command “t” in conjunction with command “u” enables indication of a 10-digit number.
Both columns are not saved in EEPROM.
4.3. Parameter commands
Command
clode
Data amount
in bytes
read write Broad-
cast
Saved in
EEPROM
Significance
a (61h) 5 X X - X Read / wriete parameters
b (62h) 8 X X - X Parameter: tolerance compensation, window
c (63h) 8 X X - X Parameter: scaling factor of spindle pitch
g (67h) 12 X X - X Parameter: limit positions MIN, MAX
h (68h) 12 X X - X Parameter: Motor speed switching points
i (69h) 1 X X X X Parameter: mm / inch
j (69h) 3 X X X X Parameter: timeout window bus error
k (6Bh) 9 X X - X Parameter: motor system times
m (6Dh) 5 X X - X Read / write general parameters
