Baumer N153 - Specific Commands

N 153
www.baumer.com 23
4.5. Specific commands
Command
code
Data amount
in bytes
read write Broad-
cast
Saved in
EEPROM
significance
K (4Bh) - - X X X Specific command: profile reset (clear)
Q (51h) 1 - X X X Specific command: SPA reset
X (58h) 2 / 4 / 8 X - - - Specific commands
4.5.1. SPA profile reset „K“ (4Bh)
This command is clearing all previously programmed profiles.
Example 1: profile reset of a specific SPA
SOH Adr Cmd Data EOT CRC
Transmission
01h 20h 4Bh
7Fh
04h C6h
SOH Adr Data EOT CRC
Response
01h 20h
6Fh
04h 52h SPA replies by standard response ‚o’ (6Fh) = OK
Example 2: profile reset in all SPAs by broadcast command (identifier=99)
SOH Adr Cmd Data EOT CRC
Transmission
01h 83h 4Bh
7Fh
04h DBh
Response Not confirmed
Important: After profile reset all profile data are set to FFFFFFhex, the current profile number to FFhex.
The SPA display now is indicating 5 hyphens instead of target.
4.5.2. SPA restore default „Q“ (51h)
This command restores default either of individual or collective parameters.
Data = q (71h) = Restore default parameters
Data = t (74h) = Device identifier = 98
Data = x (78h) = Multiturn counter reset to 0. No singleturn reset possible.
Data = ∆ (7Fh) = All above functions are accomplished.
Note: No profile reset. Profile reset by command „R“.
Example 1: Restore default in specific SPA
SOH Adr Cmd Data EOT CRC
Transmission
01h 20h 51h
7Fh
04h AEh
SOH Adr Data EOT CRC
Response
01h 20h
6Fh
04h 52h SPA replies by standard response ‚o’ (6Fh) = OK
Example 2: Restore default in all SPAs by broadcast command (identifier=99)
SOH Adr Cmd Data EOT CRC
Transmisison
01h 83h 51h
7Fh
04h B3
Response Not confirmed
4.5.3. Read version, type or serial number „X“ (58h)
This command is utilized to read version number, device type or serial number. The following sub-commands
are available:
Data = V (56h) = read version
Data = T (54h) = read device type
Data = S (53h) = read serial number
