N 153
www.baumer.com 24
Example 1 : Read version number
SOH Adr Cmd Data EOT CRC
Transmission
01h 20h 58h
56h
04h D8h
SOH Adr Cmd Data Version number = 2.00 EOT CRC
Response
01h 20h 58h 56h
20h 32h 30h 30h
04h FAh
Beispiel 2: Read device type (device type = N 153; firmware = 01)
SOH Adr Cmd Data EOT CRC
Transmission
01h 20h 58h
54h
04h DCh
SOH Adr Cmd Data Type EOT CRC
Response
01h 20h 58h 54h
93h 81h
04h 26h
Code configuration of the transmitted device type:
1 0 0 1 0 0 1 1 1 0 0 0 0 0 0 1 = 93 81 hex
┬ ──────┬────── ┬ ───────┬─────
│ │ │ └─────── software no. 01h = firmware 01
│ │ └──────────────── permanent 1
│ └────────────────────────── device type 13h = N 153
└────────────────────────────────── permanent 1
Example 3: Read serial number
SOH Adr Cmd Data EOT CRC
Transmission
01h 20h 58h
53h
04h D2h
SOH Adr Cmd Data Coded serial number = 07090EA4 EOT CRC
Response
01h 20h 58h 53h
30h 37h 30h 39h 30h 3Eh 3Ah 34h
04h 20h
Code configuration of the transmitted serial number:
The Low-Nibble (lower 4 bits of a byte) of the 8 data bits received equal together a 4 byte value comprising the
serial number.
The serial number is composed by date and time of production. Since also the seconds are coded and by as-
signing only one number per second the serial number is unique.
Example: Serial number for 01.06.2005 16:58:36 = 15 83 0E A4 hex
X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X bit position
J J J J J J M M M M T T T T T h h h h h m m m m m m s s s s s s content
0 0 0 1 0 1 0 1 1 0 0 0 0 0 1 1 0 0 0 0 1 1 1 0 1 0 1 0 0 1 0 0 Example = 15 83 0E A4 hex
─────┬───── ────┬──── ────┬──── ─────┬───── ──────┬────── ─────┬─────
│ │ │ │ │ └─────── seconds 10
0100 = 24h = 36d
│ │ │ │ └──────────────────── minutes 11
1010 = 3Ah = 58d
│ │ │ └───────────────────────────────── hours 1
0000 = 10h = 16d
│ │ └──────────────────────────────────────────── day 0
0001 = 01h = 01d
│ └────────────────────────────────────────────────────── month
0110 = 06h = 06d
└───────────────────────────────────────────────────────────────── year 00
0101 = 05h = 05d
│
01.06.05 16:58:36 <──────┘
