Baumer N153 - Dimensions; 8 Part Number

N 153
www.baumer.com 28
7.1. Dimensions
60
13
52
A
ø12
ø12
A
300
150
10
M8
female
connector
M8
connector
Cable outputConnect or output
75
20.5
22
16
13
37
6.5
45
14
30.15
31.8
26
12.5
ø14H7
ø20
1
75°
28
4.8
6
ø6h9
0.5x 45°
2:1
Pin M4
Connector
Female connector
Torque pin
Seal
Status-
LED
IR-Diode
8. Part number
Reference Interface
1 RS485
E-connection
0 Connector output
1 Cable output 4-pin M8 connector
Supply voltage
3 24 VDC
Display
A At slope
Hollow shaft
A ø14 mm
N 153.1 3 A A01
