Installation and Operating Instructions
Tachogenerator (2-piece bearingless)
TD 3 A 4 KA (DC)
WTD 3 A 4 KA (AC)
DTD 3 A 4 KA (three-phase-current)
Type: KM/RM/EM/SM
1. Generalremarks
• For reasons of clarity the operating instruction is rather general. Not all the details
for the application of tachogenerators can be explained comprehensively.
• All instructions given in this manual are generally applicable and relate to the
Baumer tachogenerator series: TD 3 A 4 KA, WTD 3 A 4 KA, DTD 3 A 4 KA / Type:
KM/RM/EM/SM.
• The tachogenerator comes with device type labels providing most important techni-
calspecications.
2. Qualiedstaff,relevantoperatorstobeaddressed
• Installationandoperationofthetachogeneratorbyqualiedpersonnelonlyandin
compliance with the relevant data sheet.
• Qualiedstaffinthesenseofpresentinstructionsisauthorizedforinstallation,
earthing and marking of devices, systems and circuits compliant to the relevant
safety standards.
3. Appropriate use
• The tachogenerator is an electromechanical measuring instrument for
voltage output in relation to speed.
• The device must only be deployed as described in the present instructions
andmustnotbeoperatedbeyondthelimitsspeciedinrelatedtechnical
documentation.
• Any other use is considered not appropriate.
• Proper and safe operation of the product is only ensured by appropriate
transport, storage, installation and mounting as well as careful operation
and diligent maintenance.
