Baumuller BUG 3 - Page 38

Installation Accessories
30 BUG 3/2/20 Basic Feed Unit
5.96064.02 Baumüller Nürnberg GmbH
Isolating transformers Autotransformers
P
M
(kVA)
Works
No.
1900 ...
U
K
(%)
Weight
(kg)
Starting current
limitation de-
vice
1)
P
M
(kVA)
Works
No.
1900 ...
U
K
(%)
Weight
(kg)
Starting current
limitation de-
vice
1)
B
U
G
2
B
U
G
20
B
U
G
3
B
U
G
2
B
U
G
20
B
U
G
3
0.4 ... 7154 4 7.5 0 0 0 0.4 ... 7159 2 4.2 0 0 0
1.0 ... 7155 4 15.0 0 0 0 1.0 ... 7160 2 7.5 0 0 0
2.5 ... 7156 4 22.5 0 0 0 2.5 ... 7161 2 15.0 0 0 0
5.0 ... 7157 4 68.0 0 0 1 5.0 ... 7162 2 22.5 0 0 1
8.0 ... 7158 4 77.0 0 0 1 8.0 ... 7163 2 27.0 1 0 1
10.0 ... 7164 2 29.0 1 0 1
15.0
2)
... 7165 2 29.0 1 0 1
25.0
2)
... 7167 2 78.0 1 1 1
1)
Starting current limitation device
0: Not necessary
1: Operation with starting current limitation device only
2)
These transformers have an additional tap for 190 V; 40-kVA transformers on request
