Audio Frequency Generator TG 600
Output power at 2 kHz in 2 steps 600VA / 60VA
at 10kHz in 2 steps 450VA / 45VA
Output current max. 30 A
Output impedance in 8 steps
0.3 / 0.8 / 1.8 / 4 / 10 / 30 / 100 / 300 W
Frequencies Quarz-stabilized: 2kHz and 10kHz;
other frequencies on request
Operating modes Continuous operation and impulse operation
Display 2 instruments for indication of I
in
and I
out
Reactive power
compensation adjustable in 63 steps
Power supply 110/120, 220/230 V, 50-60Hz
Power consumption 1800VA at 600VA output power
Overload protection Overtemperature switch-off and indication
Operating temperature -20°C to +40°C
Dimensions 505 x 255 x 330 mm
Weight approx. 38 kg
