Baxi PRIME - States and Sub-States

11
USER Section (en)
7654349 (02-09/16)
STATES AND SUB-STATES
• 7KH67$7(LVWKHSKDVHRIRSHUDWLRQRIWKHERLOHUDWWKHWLPHLWLVGLVSOD\HG
• 7KH68%67$7(LVWKHSKDVHRILQVWDQWDQHRXVRSHUDWLRQRIWKHERLOHUDWWKHWLPHLWLVGLVSOD\HG
STATE LIST
STATE
DISPLAY
STAND BY
t00
HEAT DEMAND
t01
BURNER IN IGNITION
t02
OPERATION IN THE HEATING MODE
t03
OPERATION IN THE DHW MODE
t04
BURNER OFF
t05
PUMP POST CIRCULATION
t06
TURNING OFF THE BURNER TO REACH THE TEMPERATURE SETPOINT
t08
TEMPORARY FAULT
t09
PERMANENT FAULT (A FAULT TO BE RESET MANUALLY)
t10
FLUE CLEANING FUNCTION AT MINIMUM POWER
t11
FLUE CLEANING FUNCTION AT MAXIMUM POWER IN CH MODE
t12
FLUE CLEANING FUNCTION AT MAXIMUM POWER IN DHW MODE
t13
MANUAL HEAT DEMAND
t15
FROST PROTECTION ENABLED
t16
VENTING FUNCTION ENABLED
t17
ELECTRONIC BOARD OVERHEATED (WAIT FOR IT TO COOL DOWN)
t18
RESETTING BOILER
t19
SUB-STATE LIST
SUB-STATE DISPLAY
STAND BY
U00
DELAY BEFORE CH IS NEXT STARTED
U01
PRE-VENTILATION
U13
BURNER PRE-IGNITION
U17
ATTEMPT TO IGNITE BURNER
U18
FLAME CONTROL
U19
RUNNING OF FAN DURING IGNITION ATTEMPTS
U20
OPERATION AT SET TEMPERATURE SETPOINT
U30
OPERATION AT LIMITED TEMPERATURE SETPOINT
U31
OPERATION AT MAXIMUM AVAILABLE POWER
U32
LEVEL 1 GRADIENT DETECTED
U33
LEVEL 2 GRADIENT DETECTED
U34
LEVEL 3 GRADIENT DETECTED
U35
FLAME PROTECTION ENABLED
U36
STABILISATION TIME
U37
BOILER STARTED AT MINIMUM POWER
U38
POST-VENTILATION
U41
TURNING OFF FAN
U44
REDUCTION OF POWER FOR HIGH FLUE TEMPERATURE
U45
PUMP POST-CIRCULATION
U60
