ENUSER’S MANUAL XTI

1. BEFORE USING

Place this product on a firm and smooth place, don’t place it in vibration or shaking, use bench for use on four only adjust foot, adjust

the balance using the bubble level.

Use independent source, avoid other electrical disturbance.

Don’t put any object on the platter when turn on the balance.

Please, turn on 2-3 minutes before using.

Avoid temperature change too large and air flow strenuous sites.

Don’t overload the balance, don’t exceed the maximal capacity.

2. SPECIFICATIONS

XTI

Accuracy Clase III

Loadcell sensitivity range 1.5 ~ 3.0mV/V

Nonlinear ≤0.01%F.S

System working voltage DC:5V

Division 2/5-5/10

Large LCD display connector Sampling serial output way

Sample rate 20 times per second (can select)

Internal resolution 300000~600000

3. POWER

Input 120~240V

Output 12V/1A

Rechargeable battery 6V/4Ah

4. SYSTEM POWER CONSUMPTION

Main system power consumption about 12mA

Main system power consumption (with backlight) about 36mA

Battery life, none backlight about 320 hours

5. LOW POWER WARNING

• When the battery voltage is below 5.6V, the low power indicator on the LCD display will light up.

• When the battery voltage is below 5.5V, the low power indicator on the LCD display will start to flash.

• When the battery voltage is below 5.4V, the scale will turn off.
