WARNING !
The Error LED can be active before calibration. Do not care the error status
before performing the calibration of your weighing system.
Contents :
SECTION
CONTENTS PAGE
1. Features 2
2. Installation and Commissioning 3
2.1 Mechanical Installation 3
2.2 Electrical Connections 3
2.3 Load Cell Connection 4
2.4 Analogue Output Connection 5
2.5 Input and Outputs ( only TX 1W ) 5
2.6 Serial port RS232C ( only TX 1W ) 5
2.7 Commissioning 6
3. Operation 6
4. Programming via Keys 6
4.1 Changing the Analogue Output Mode 7
4.2 Setup and Calibration 7
5. Programming by PC software 10
6. Housing Dimensions 11
7. Trouble Shooting 11
PRECAUTIONS
Don’t let unauthorized people interfere with the instrument.
Check the supply voltage, the load cell and especially the ground
connections before energizing TX 1.
Don’t energize TX 1 before making the load cell connection.
Don’t connect / disconnect the cables and/or connectors while TX 1 is
energized.
Do not open the enclosure while TX 1 is connected to the power supply.
