Chapter 11: Electrical System 197, 219, & 249 • Owner’s Manual
Supplement
72
219 Battery System
249 Battery System
BATTERY
ENGINE GROUND
ENGINE
NOTE: POSITIVE BATTERY CABLES ARE RED
NEGATIVE BATTERY CABLES ARE YELLOW
POSITIVE
NEGATIVE
BATTERY
ENGINE
ENGINE GROUND
NOTE: POSITIVE BATTERY CABLES ARE RED
NEGATIVE BATTERY CABLES ARE YELLOW
POSITIVE
NEGATIVE
