Bazooka BT6014 - Mounting the Bazooka

8
Figure 5
3
,,
3
,,
Figure 4
4. Move the bases so that they are spaced approximately 3 from each
end of the enclosure as illustrated in figure 5.
5. Remove the Bass Tubes
®
enclosure without moving the mounting
bases and set it aside.
6. Screw each mounting base securely in place with screws provided
as illustrated in figure 3.
3. Place each mounting base under the Bass Tubes
®
enclosure so that
the apex at the bottom of the tube sits inside the mounting base as
in figure 4.
ENGLISH
7
1. With the topside of the buckle facing up (see figure 1), lace the strap
through the mounting base as illustrated in figure 2
MOUNTING THE BAZOOKA
2. After the strap is completely laced through the mounting base, make
a loop with the strap, where it runs across the middle of the base as
illustrated in figure 3. This loop is necessary to access the two mounting
holes in the base.
Figure 1
Figure 2
Figure 3
To p
Logo
should
face up
ENGLISH
