Bazooka CS8A5 - System Features; Specifications; Installation

8” SUBWOOFER
PATENTED BASS TUBES
®
ENCLOSURE WITH BASS REFLEX/DUCTED PORT ALIGNMENT*
HIGH EFFICIENCY OUTPUT
OPTIMIZED FOR SPACE EFFICIENCY
DESIGNED FOR CORNER LOADING
MOISTURE RESISTANT ENCLOSURE
BUILT IN 50 WATT MAX AMPLIFIER POWER
18dB ELECTRONIC CROSSOVER FIXED @ 85 Hz.
NOISE REJECTING BALANCED INPUT CIRCUITRY
INPUTS ARE SUMMED MONO INTERNALLY
SELECTABLE AUTOMATIC TURN ON FEATURE
12dB PER OCTAVE SUBSONIC FILTER @ 35 Hz.
* The efficiency levels of all Bazooka subwoofer speaker systems are measured in the typical
environment: In the low bass region with one watt of power.
SYSTEM FEATURES
SPECIFICATIONS
3
BASS TUBES
®
enclosure - patented Bass Reflex/ducted port alignment
TA850
Woofer Size 8
Voice Coil Size 1 high power /high temp
Magnet Size 15 oz.
Frequency response 39-85 hz.
Efficiency 105 dB*
Dimensions 18.125x8.5x10
Weight 15.5 lbs.
Impedance 2 ohms
*BAZOOKA
®
subwoofer speaker systems exclusively incorporate the revolutionary Bass Tubes
®
patented subwoofer enclosure design available only from SAS.
®
4
INSTALLATION
Figure 1
Figure 2
Figure 3
