Materials to Pic (1)
No. PARTS CODE PARTS NAME Q ty
14692200 SF-HD60 1
1
1EA0311A06300 ASSY, CHASSIS, COMPLETE 1
2
1EA0M10A15500 ASSY, MOTOR, SLED 1
Or
1EA0M10A15501 ASSY, MOTOR, SLED 1
3
1EA2451A24700 HOLDER, SHAFT 3
4
1EA2511A29100 GEAR, RACK 1
5
1EA2511A29200 GEAR, DRIVE 1
6
1EA2511A29300 GEAR, MIDDLE, A 1
7
1EA2511A29400 GEAR, MIDDLE, B 1
8
1EA2744A03000 SHAFT, SLIDE 1
9
1EA2744A03100 SHAFT, SLIDE, SUB 1
10
1EA2812A15300 SPRING, COMP, TYOUSEI 3
11
1EA2812A15400 SPRING, COMP, RACK 1
21
1EA0B10B20100 ASSY, PWB 1
Or
1EA0B10B20200 ASSY, PWB 1
31
SEXEA25700--- SPECIAL SCREW BIN+-M2X11 3
32
SEXEA25900--- SPECIAL SCREW M1.7X2.2 2
33
SFBPN204R0SE- SCR S-TPG PAN 2X4 2
34
SFSFN266R0SE- SCR S-TPG FLT 2.6X6 1
35
SWXEA15400--- SPECIAL WASHER 1.8X4 X0.25 2

Note : This parts list is not for service parts supply.
