BBK DV113S - DV113 S Material List - Power Board; Power Board Components List

DV113S MATERIAL LIST
1. POWER BOARD
MATERIAL CODE MATERIAL NAME SPECIFICATIONS UNIT
Q
UANTIT
Y
LOCATION
294 CARBON FILM RESISTOR 1/4W10K±5% SHAPED 10 PCS 1 R507
0010064 METAL FILM RESISTOR 1/4W10K±1% SHAPED 10 PCS 1 R509
0000461 CARBON FILM RESISTOR 1/4W9.1K±5% SHAPED 10 PCS 1 R512
0010256 METAL FILM RESISTOR 1/4W3.6K±1% SHAPED 10 PCS 1 R508
0000431 CARBON FILM RESISTOR 1/4W75Ω±5% SHAPED 10 PCS 1 R505
10135
METAL OXIDE FILM
RESISTO
R
2W39K±5% SHAPED FLAT 15×9 PCS 1 R503
0000278 CARBON FILM RESISTOR 1/4W330Ω±5% SHAPED 10 PCS 1 R517
0000380 CARBON FILM RESISTOR 1/4W510Ω±5% SHAPED 10 PCS 1 R506
0070001
HIGH VOLTAGE
RESISTO
R
1/2W680K±5% PCS 1 R501
0580054
VOLTAGE REGULATOR
DIODE
9.1V 1W PCS 1 ZD502
10250
METAL OXIDE FILM
RESISTO
R
1W22Ω±5％ SHAPED R 15×8
PCS 1 R511
0570005 DIODE 1N4007 PCS 4 D501~D504
0570011 DIODE RL202 PCS 2 D509,D513
0200138 PORCELAIN CAPACITOR 50V 104 ±20% 5mm PCS 4 C504,C508,C510,C515
0200224 PORCELAIN CAPACITOR 1000V 103 +80%-20% 7.5mm PCS 1 C502
0200223 PORCELAIN CAPACITOR 1000V 101 +80%-20% 7.5mm PCS 1 C503
0200228 PORCELAIN CAPACITOR 1000V 101 ±10% 7.5mm PCS 1 C503
210191 TERYLENE CAPACITOR 50V 222 ±10% 5mm PCS 1 C506
0260559 CD CD11T 50V47U±20%6×12 2.5 PCS 2 TC502,TC512
0260563 CD KM 400V47U±20%18×20 7.5 PCS 1 TC501
260557 CD CD11T 16V100U±20%6×12 2.5 PCS 1 TC513
0260594 CD CD11T 25V220U±20%8×12 3.5 PCS 2 TC503,TC504
0260560 CD CD11T 10V1000U±20%8×16 3.5 PCS 3 TC505,TC506,TC510
0390057
MAGNETIC BEADS
INDUCTO
R
RH354708 PCS 1 L503
0410010 CHOKE COIL VERTICAL 10UH 1A 5mm PCS 1 L505
0410011 CHOKE COIL VERTICAL 10UH 2A 5mm PCS 1 L507
1080011
PHOTOELECTRIC
COUPLE
R
HS817 PCS 1 U502
0570013 DIODE HER105 PCS 3 D506,D508,D511
570014 DIODE HER107 PCS 1 D505
0680010 SCHOTTKY DIODE SR560 DO-27 PCS 1 D510
0880553 IC LM431ACZ TO-92 PCS 1 U503
0880581 IC TL431C TO-226AA(LP) PCS 1 U503
0880800 IC 431L TO-92 PCS 1 U503
0210066 TERYLENE CAPACITOR 275V 104 ±20% 15mm PCS 1 BC501
0210070 TERYLENE CAPACITOR 275V 104 ±10% 15mm PCS 1 BC501
200267 CERAMIC CAPACITOR CT81 250VAC221±20% 10mm PCS 1 BC503
0200268 CERAMIC CAPACITOR CT81 250VAC221±10% 10mm PCS 1 BC503
0460394
SWITCHING POWER
TRANSFORME
R
BCK-19-0179 PCS 1 T501
1000004 POWER GRID FILTER UT-20 40mH ±20% 10×13 PCS 1 L501
1563407 PCB 5501A-4 PCS 1
2100003 CONNECTION CORDS Φ0.6 SHAPED 7.5mm PCS 2 JP501,JP503
2100010 CONNECTION CORDS Φ0.6 SHAPED 5mm PCS 1 JP502
2300021 FUSE T1.6AL 250V PCS 1 F501
1940045 SOCKET 2P 8.0mm 2# PCS 2 BCN501,BCN502
1940023 SOCKET 7P 2.0mm PCS 1 CN502
1940027 SOCKET 2P 2.0mm PCS 1 CN501
0881933 IC VIPER22A DIP8 PCS 1 U501
3870115
GROUND CHIP OF
POWER BOARD
AB903 PCS 2 G501,G502
2. MAIN PANEL
MATERIAL CODE MATERIAL NAME SPECIFICATIONS UNIT
Q
UANTIT
Y
LOCATION
5232805 SOFT SPONGE SPACER 6×6×2.5 DOUBLE-FACED HARD PCS 1 1PC FOR IR SENSOR
9 CARBON FILM RESISTOR 1/6W100Ω±5% PCS 1 R415
0090023 SMD RESISTOR 1/16W 10K ±5% PCS 3 R416,R417,R418
0570006 DIODE 1N4148 PCS 1 D401
1340003
LIGHT TOUCH RESTORE
SWITCH
HORIZONTAL 6×6×1 PCS 3 K401~K403
0200139 PORCELAIN CAPACITOR 50V 104 +80%-20% 5mm PCS 1 C405
0260206 CD CD11C 10V100U±20%5×7 2 PCS 1 TC407
2360002 IR SENSOR HS0038B PCS 1 U403
