BBK DV113S - Page 35

2100010 CONNECTION CORDS Φ0.6 SHAPED 5mm PCS 1 JP401
2121370 FLAT CABLE
6P170 2.0 2PLUG WITH L
NEEDLE REVERS
E
PCS 1 XS401
1563482 PCB 4911S-1 PCS 1
3. AV BOARD
MATERIAL CODE MATERIAL NAME SPECIFICATIONS UNIT
Q
UANTIT
Y
LOCATION
362 CARBON FILM RESISTOR 1/4W220Ω±5% SHAPED 10 PCS 1 R701
0000123 CARBON FILM RESISTOR 1/6W330Ω±5% SHAPED 7.5 PCS 1 R709
0090005 SMD RESISTOR 1/16W 33Ω ±5% 0603 PCS 1 R708
0090181 SMD RESISTOR 1/16W 100Ω ±5% 0603 PCS 1 R702
0090002 SMD RESISTOR 1/16W 2.2Ω ±5% 0603 PCS 1 R706
0090019 SMD RESISTOR 1/16W 4.7K ±5% 0603 PCS 1 R704
0000129 CARBON FILM RESISTOR 1/6W1K±5% SHAPED 7.5 PCS 1 R711
0090017 SMD RESISTOR 1/16W 2.2K ±5% 0603 PCS 2 R710,R712
0090006 SMD RESISTOR 1/16W 75Ω ±5% 0603 PCS 1 R705
310066 SMD CAPACITOR 50V 102 ±10% 0603 PCS 2 C705,C706
0310207 SMD CAPACITOR 50V 104 ±20% X7R 0603 PCS 3 C707,C710,C716
0310543 SMD CAPACITOR 50V 104 ±10% X7R 0603 PCS 3 C707,C710,C716
0310222 SMD CAPACITOR 25V 104 ±20% X7R 0603 PCS 3 C707,C710,C716
0090001 SMD RESISTOR 1/16W 0Ω ±5% 0603 PCS 6 R717~R721,R707
780050 TRIODE S8050D PCS 3 V701~V703
390057
MAGNETIC BEADS
INDUCTO
R
RH354708 PCS 10 L705~L714
1910140 TERMINAL SOCKET AV4-8.4-5G-5 BLACK PCS 1 JK701
1910129 TERMINAL SOCKET
SA-001-012 BLACK IRON PIECE
SCREEN-SHIELDE
D
PCS 1 JK703
1940140 CABLE SOCKET
14P 1.0mm STRAIGHT DUAL
LINE PLU
G
PCS 1 XS701
2100010 CONNECTION CORDS Φ0.6 SHAPED 5mm PCS 3 JP704,JP710,JP711
2100003 CONNECTION CORDS Φ0.6 SHAPED 7.5mm PCS 5 JP705~JP709
2100004 CONNECTION CORDS Φ0.6 SHAPED 10mm PCS 3 JP701~JP703
1860029 SCART SOCKET SCART-01 PCS 1 JK706
1563648 PCB 7112S-0 PCS 1
4. OKV BOARD
MATERIAL CODE MATERIAL NAME SPECIFICATIONS UNIT
Q
UANTIT
Y
LOCATION
0000126 CARBON FILM RESISTOR 1/6W560Ω±5% SHAPED 7.5 PCS 1 R603
0000129 CARBON FILM RESISTOR 1/6W1K±5% SHAPED 7.5 PCS 1 R607
90014 SMD RESISTOR 1/16W 1K ±5% 0603 PCS 2 R619,R626
0090026 SMD RESISTOR 1/16W 22K ±5% 0603 PCS 1 R601
0090019 SMD RESISTOR 1/16W 4.7K ±5% 0603 PCS 3 R622,R628,R623
0090020 SMD RESISTOR 1/16W 5.1K ±5% 0603 PCS 1 R616
0090023 SMD RESISTOR 1/16W 10K ±5% 0603 PCS 5
R605,R617,R620,R621,R62
4
137 CARBON FILM RESISTOR 1/6W10K±5% SHAPED 7.5 PCS 1 R612
0390057
MAGNETIC BEADS
INDUCTO
R
RH354708 PCS 1 L602
0000118 CARBON FILM RESISTOR 1/6W10Ω±5% SHAPED 7.5 PCS 2 R632,R633
0090024 SMD RESISTOR 1/16W 15K ±5% 0603 PCS 1 R618
0000338 CARBON FILM RESISTOR 1/6W15K±5% SHAPED 7.5 PCS 1 R614
90188 SMD RESISTOR 1/16W 18K ±5% 0603 PCS 1 R615
0000144 CARBON FILM RESISTOR 1/6W47K±5% SHAPED 7.5 PCS 1 R610
0090027 SMD RESISTOR 1/16W 27K ±5% 0603 PCS 1 R629
0090028 SMD RESISTOR 1/16W 33K ±5% 0603 PCS 2 R609,R613
0090018 SMD RESISTOR 1/16W 3.3K ±5% 0603 PCS 1 R608
0260127 CD CD11 16V4.7U±20%5×11 2 PCS 7
TC601,TC603,TC607,TC61
0,TC611,
TC613
,
TC621
260021 CD CD11 16V22U±20%5×11 2 PCS 1 TC605
0260200 CD CD11C 16V47U±20%5×7 2 PCS 2 TC608,TC609
0260040 CD CD11 25V100U±20%6×12 2.5 PCS 2 TC615,TC616
0310047 SMD CAPACITOR 50V 101 ±5% NPO 0603 PCS 3 C605,C607,C620
0310066 SMD CAPACITOR 50V 102 ±10% 0603 PCS 3 C619,C625,C606
0310072 SMD CAPACITOR 50V 103 ±10% 0603 PCS 2 C603,C616
0310084 SMD CAPACITOR 50V 104 +80%-20% 0603 PCS 8
C602,C609,C613,C614,C62
2,C623,C601,C604
0310058 SMD CAPACITOR 25V 104 +80%-20% 0603 PCS 8
C602,C609,C613,C614,C62
2,C623,C601,C604
0310323 SMD CAPACITOR 50V 392 ±10% 0603 PCS 2 C615,C608
