BBK DV113S - Page 36

0310197 SMD CAPACITOR 50V 561 ±10% 0603 PCS 2 C610,C612
0390095 SMD MAGNETIC BEADS FCM1608K-221T05 PCS 2 L601,L603
0880124 IC NJM4558D DIP PCS 2 U601,U602
2121509 FLAT CABLE
6P200 2.0 2PLUG WITH L
NEEDLE REVERS
E
PCS 1 XS601
2100010 CONNECTION CORDS Φ0.6 SHAPED 5mm PCS 2 JP603,JP605
2100003 CONNECTION CORDS Φ0.6 SHAPED 7.5mm PCS 5
JP601,JP602,JP604,JP606,J
P607
1980048 MIC SOCKET ST-403-070-100 PCS 1 MIC602
0160184
ROTATED
POTENTIOMETE
R
WH09JTC1Z11-A10K-F30 PCS 1 VR602
1563776 PCB 6911S-1 PCS 1
880230 IC PT2399 DIP PCS 1 U603
5. OKV BOARD
MATERIAL CODE MATERIAL NAME SPECIFICATIONS UNIT
Q
UANTIT
Y
LOCATION
0090001 SMD RESISTOR 1/16W 0Ω ±5% 0603 PCS 35
L235,L237~L239,L310,L31
2,L314,L316,L317,L319,L3
20,R201,R203,R209,R211~
R213,R222,R226,R236,R24
5,R247,R249,R251,R279,R3
31,R339,R340,R342,R344,R
347,R349,R351,R2161,R282
0090214 SMD RESISTOR 1/16W 2.2MΩ ±5% 0603 PCS 1 R281
0090272 SMD RESISTOR 1/16W1Ω±5% 0603 PCS 5 R304~R307,R321
0090106 SMD RESISTOR 1/16W 4.7Ω ±5% 0603 PCS 4 R206,R228,R301,R302
0090006 SMD RESISTOR 1/16W 75Ω ±5% 0603 PCS 5 R233,R217,R219~R221
0090005 SMD RESISTOR 1/16W 33Ω ±5% 0603 PCS 15
R255,R261~R268,R291~R2
96
0090009 SMD RESISTOR 1/16W 330Ω ±5% 0603 PCS 2 R325,R326
0090014 SMD RESISTOR 1/16W 1K ±5% 0603 PCS 12
R215,R254,R259,R260,R32
3,R324,R2103,R2117~R212
0
,
R205
0090016 SMD RESISTOR 1/16W 1.5K ±5% 0603 PCS 1 R243
0090249 SMD RESISTOR 1/16W 510Ω ±5% 0603 PCS 1 R214
0090018 SMD RESISTOR 1/16W 3.3K ±5% 0603 PCS 2 R242,R2104
0090019 SMD RESISTOR 1/16W 4.7K ±5% 0603 PCS 8
R216,R238~R240,R2130,R2
131,R2134,R2135
90021 SMD RESISTOR 1/16W 6.8K ±5% 0603 PCS 2 R2136,R2148
0090023 SMD RESISTOR 1/16W 10K ±5% 0603 PCS 15
R252,R309,R311,R313,R31
4,R328~R330,R332,R333,R
2102,R2106,R2108,R2109,R
274
0090024 SMD RESISTOR 1/16W 15K ±5% 0603 PCS 2 R223,R334
0090188 SMD RESISTOR 1/16W 18K ±5% 0603 PCS 1 R335
0090025 SMD RESISTOR 1/16W 20K ±5% 0603 PCS 6
R312,R315,R316,R336,R21
32,R2156
90255 SMD RESISTOR 1/16W24K±5% 0603 PCS 2 R2129,R2133
0090034 SMD RESISTOR 1/16W 100K ±5% 0603 PCS 7
R224,R246,R308,R310,R21
01,R2111~R2112
0090197 SMD RESISTOR 1/16W 150K ±5% 0603 PCS 2 R319,R320
0090231
PRECISION SMD
RESISTO
R
1/16W 680K ±1% 0603 PCS 2 R317,R318
0090319
PRECISION SMD
RESISTO
R
1/16W 750K ±1% 0603 PCS 1 R227
375 CARBON FILM RESISTOR 1/4W2.2Ω±5% PCS 1 R327
0260019 CD CD11 16V10U±20%5×11 2 PCS 9
TC201,TC202,TC217,TC22
5~TC226,TC232,TC233,TC
240
,
TC241
0260009 CD CD11 10V47U±20%5×11 2 PCS 12
TC203~TC206,TC211,TC2
37,TC238,TC302~TC304,T
C308
,
TC309
0260012 CD CD11 10V100U±20%5×11 2 PCS 2 TC214,TC231
0260040 CD CD11 25V100U±20%6×12 2.5 PCS 2 TC215,TC216
0260013 CD CD11 10V220U±20%6×12 2.5 PCS 8
TC207~TC209,TC212,TC2
36,TC245,TC301,TC305
0260028 CD CD11 16V220U±20%6×12 2.5 PCS 1 TC235
0310043 SMD CAPACITOR 50V 22P ±5% NPO 0603 PCS 3 C222,C275,C276
0310045 SMD CAPACITOR 50V 47P ±5% NPO 0603 PCS 8
C253,C254,C257,C258,C25
9~C262
0310047 SMD CAPACITOR 50V 101 ±5% NPO 0603 PCS 2 C2111,C2114
