BBK DV214SI(RU) - Page 46

REVOC POT1SCP56*08REPAP NOITALUSNI1-00S412-03561.2
2.17 281-088801-0
POWER CABLE
BANDING WIRE KNOT
L=125MM W=10MM' PCS 1
2.18 501-250805-10 RUBBER EVA90 L25*8MM*5MM(25*8) PCS 2 LOADER
2.19 502-140040-11 SPRRONG CUSHION EVA90 φ14MM*4MM PCS 2 BUTTOM CABINET
2.20 501-170808-12 SPRRONG CUSHION EVA90 L17*W8*H6MM PCS 2 FRONT PANEL
2.21 551-318S01-0
DOUBLE-FACE YELLOW
ADHESIVE TAPE
150MM (9M/R 9MM) PCS 1
2.23 533-080310-0 RED PAD φ8MM*3MM H=1.0MM PCS 2 MPEG BOARD
2.24 191-078080-3D FLAT CABLE
A：7PIN, B:6PIN 24# 2.54MM L=80
M
PCS 1
2.25 171-430120-0 POWER CABLE (H03VVH2-F):L=1200MM+200MM PCS 1
SERIA
L
NUMB
MATERIAL CODE MATERIAL NAME SPECIFICATIONS UNIT
Q
UANTIT
Y
LOCATION
3 821-051217-0 DECODER BOARD
MTK1389DE-L(SKY-CX2:022009-
06-25)
SET 1
3.1 160-006300-0
PIN SOCKET
1NC1SCPNIP6 A6-HX
3.2 160-006200-0
PIN SOCKET
3NC1SCPNIP6 A6-HP
3.3 160-004200-0
PIN SOCKET
4NC1SCPNIP4 A4-HP
3.4
160-005200-0 PIN SOCKET
PH-5A 5PIN
PCS 1 CN6
3.5
160-007200-0 PIN SOCKET
PH-7A 7PIN
PCS 1 CN2
3.6
160-010200-0 PIN SOCKET
PH-10A 10PIN
PCS 1 CN10
3.7
160-003200-0 PIN SOCKET
PH-3A 3PIN
PCS 1 CN11
3.8
060-124051-0
FPC SOCKET
FPC 24PIN
PCS 1 CN5
3.9
161-434054-0
AV-S VIDEO JACK
S-VIDEO
PCS 1 P1
3.10
161-134234-0
RCA JACK
3RCA
PCS 1 P2
3.11
127-106042-3
01SCPROTICAPAC
C27,C123,C124,C131,C132
,C7
3.12
127-476048-0
CAPACITOR
47uF/16V +80% -20% 4*7mm
PCS 12
C4,C13,C18,C33,C34,C64,
C67
3.13
127-107032-5
CAPACITOR
100uF 10V ±20% Φ6.3*7mm -40℃
+105℃
PCS 4 C21,C54,C78,C36
3.14
127-107042-3
CAPACITOR
100uF/16V ±20% 6.3*7mm
PCS 1 C155
3.15
127-227032-8
CAPACITOR
220uF/10V ±20% 6.3*7mm -
40+105℃
PCS 5 C32,C118,C9,C3,C12
3.16 127-477032-1 CAPACITOR
470uF/10V ±20% 8*12MM
PCS 1 C40
3.17
023-270040-00 CHIP CAPACITOR
27PF 16V ±5% 0402
PCS 2 C56,C57
3.18
023-101040-00 CHIP CAPACITOR
PCS 13
C28,C103,C104,C108C115,
C1
3.19 023-221041-00
CHIP CAPACITOR
220PF 16V ±10% 0402 PCS 1 C162
3.20 023-331041-00
CHIP CAPACITOR
330PF 16V ±10% 0402
PCS 2 C69,C70,C130
3.21
023-152041-00 CHIP CAPACITOR
1500PF 16V ±10% 0402
PCS 3 C48
3.22
023-102041-00 CHIP CAPACITOR
PCS 4 C125,C126,C133,C134
3.23
023-332041-00 CHIP CAPACITOR
3300PF 16V ±10% 0402 PCS 1 C142
3.24
023-682041-00 CHIP CAPACITOR
6800PF 16V ±10% 0402 PCS 1 C35
3.25
023-153041-00 CHIP CAPACITOR
15nF 16V ±10% 0402 PCS 1 C72
3.26
023-104042-00 CHIP CAPACITOR
100nF 16V ±20% 0402 PCS 24
C5/6/10/11/19/22/23/25/29/
3
3. DV214SI SILVER MTK1389DE-L DECODER BOARD COMPONENTS 821-051217-0
-41-
