Attaching Implements
Models 710 - 728 - 738 - 740
Implementsareeithermounteddirectlytotheange
(g.12,A) or coupled with the quick release
assembly
(g.13,C) . It is important that nuts (g.13,D) which fasten the implement and the
bushing are well tightened.
Model 750
Implements are mounted directly to the machine coupler
(g.14,A) by attaching the coupler (g.
14, C)
thatisxedtotheimplement.
Thettingandremovalofattachmentsisachievedbyrotatingtheknob
(g.15,R) . The the device
is locked by turning the knob clockwise and unlocked by the knob anti-clockwise. It is important that
nuts
(g.15,D) which fasten the implement and the bushing are well tightened.
Fig. 12 Fig. 13
Fig. 14 Fig. 15
R
A
C
D
A
C
D
