Chapter 2: System overview 17
The enclosure has these features:
• Sheath filter holder on one end
• Plenum cap holder on other end
• The sheath plenum, which slides out to the side after opening
the cover and disconnecting caps and tubing
More information • Changing the sheath filter (page 39)
Specifications and requirements
Introduction This topic lists the specifications and requirements for the product.
Physical • Height: 57 cm (22.4 in.)
• Width: 62 cm (24.4 in.)
• Depth: 73 cm (28.7 in.)
• Weight: 22 kg (48.4 lb). The weight of the unit does not
include the weight of full BD FACSFlow sheath or waste
cubitainers.
Electrical • Input voltage/Hz: 100–240, VAC 50–60 Hz
• Current:
– 0.5 A (at 120 V)
– 0.3 A (at 220 V)
• Fuse: 1 A T
Item Description
1Cap holder
2 Sheath plenum
3 Sheath filter
