Bdcom P1501C1 User Manual

9
4 Technical Indexes
Main Technical Specifications
Standard EPON Standard IEEE802.3ah
Data
transmission
rate
Uplink 1Gbps
Downlink 1Gbps
Interface
One optical interface Single mode
4 to 24 fast-Ethernet
ports
RJ-45, 10/100Mbit/s, MDI/MDIX
auto-adaptation
Physical Features and Environmental Requirements
Model
Parameter
P1501C1 P1501C2
Power input of
the power adapter
100V-240VAC 100V-240VAC
Frequency
50Hz-60Hz
Power supply for
the whole
machine
12V DC,1A 12V DC,1A
Standard power
consumption
<16W
Working
temperature
0 ˚ C-40 ˚ C
Working
humidity
5%-95% (non-condensing)
Dimensions
(W*H*D)
133×103×29 170×98×28
Weight
<0.5kg <0.5kg

Bdcom P1501C1 Specifications

General

Brand	Bdcom
Model	P1501C1
Category	Network Hardware
Language	English
