15
4.7 Fuel tank cap
Remove the fuel tank cap by turning it counterclockwise.
4.8 Ground (Earth) terminal
Ground (Earth) terminal (1) connects the earth line for the prevention
of an electric shock. All electrical tools and appliances operated from
this generator must be properly grounded by use of a third wire or
have cords that are “Double Insulated”
CONTROL FUNCTION
THE GENERATOR (STATOR WINDING) IS ISOLATED FROM THE FRAME AND
FROM THE AC RECEPTACLE GROUND PIN.
ELECTRICAL DEVICES THAT REQUIRE A GROUNDED RECEPTACLE PIN
CONNECTION WILL NOT FUNCTION IF THE RECEPTACLE GROUND PIN IS NOT
FUNCTIONAL.
