BE BE3500IP - Page 72

9
3. DESCRIPTION
2 . DISCRIPTION
① Carrying handle
②
③
Fuel tank cap
④
Control panel
⑤
Recoil starter
⑥
Oil filler cap
⑦
Louver
⑧
Muffler
Spark plug maintenance cover
- 8 -
2 .1 Control panel
1. Poignee De Transport
2. Bouchon du réservoir de carburant
3. Panneau de contrôle
4. Démarreur de recul
5. Capuchon de remplissage d’huile
6. Persienne
7. Silencieux
8. Couvercle de bougie d’allumage
3. CONTROL FUNCTION
3.1 Switch knob
3.2 LED functions display(For electric start version)
① Engine switch \fuel valve “OFF”;
Ignition circuit is switched off. Fuel is switched off.
The engine will not run.
② Engine switch \fuel valve \ choke “ON”
Ignition circuit is switched on. Fuel is switched on. Choke is switched on.
The engine can be running.
③ Engine switch \fuel valve \ choke “CHOKE” ;
Ignition circuit is switched on. Fuel is switched on. Choke is switched off.
The engine can be start.
TIP: The choke is not required to start a warm engine.
;
- 10 -
ElectricRecoil
25% 50% 75% 100% 110%
Oil change indicator
Air cleaner maintenance indicator
Spark plug maintenance indicator
Switch button
Fuel level indicator
On-load indicator
Oil alert indicator
Inveter alert indicator
Inverter running indicator
Power display
Multi functional digital meter
4
4
3
3
5
5
6
6
7
7
8
8
9
9
10
10
11
11
2
2
1
1
󰀩
1. Indicateur de changement d’huile
2. Entretien du nettoyeur d’air
3. Entretien de la bougie d’allumage
4. Le bouton de l’interrupteur
5. Compteur de fonctions multiples
6. Indicateur de carburant
7. Indicateur en charge
8. Indicateur d’alerte au pétrole
9. Indicateur de course
10. Indicateur d’alerte de l’onduleur
11. 󰀩
DESCRIPTION
