safety
WARNING
The high pressure stream of water that this
equipment produces can cut through skin and
its underlying tissues, leading to serious injury
and possible amputation.
Spray gun traps high water pressure, even when
engine is stopped and water is disconnected.
This can cause injury if it is not released.
• DO NOT allow CHILDREN to operate pressure washer.
• NEVER repair high pressure hose. Replace it.
• NEVER repair leaking connections with sealant of any kind.
Replace o-ring or seal.
• NEVER connect high pressure hose directly to nozzle
extension.
• Keep high pressure hose connected to pump and spray
gun while system is pressurized.
• ALWAYS point spray gun in a safe direction and squeeze
the trigger to release high pressure every time you stop the
engine.
• NEVER aim spray gun at people, animals, or plants.
• DO NOT leave spray gun unattended while machine is
running.
• NEVER use a spray gun which does not have a trigger lock
or trigger guard in place and in working order.
• Always be certain spray gun, nozzles, and accessories are
securely attached.
NOTICE
High pressure spray may damage fragile items including
glass and screens.
• Never point spray gun at glass when using red 0° spray tip.
• NEVER aim spray gun at plants.
The following diagram is intended for general
reference purposes. Your washer may dier
from the unit shown below. For specific model
information, spec sheets, and breakdowns, visit:
BEPOWEREQUIPMENT.COM
electric washer components
1. Frame/Mounting Bracket
2. Quick-Connect Nozzles
3. Spray Gun & Lance
4. Soap Tank
5. Brush Holder
6. Washer Assembly (Pump & Motor)
7. High-Pressure Hose Reel
2.
4.
5.
1.
3.
7.
6.
