How to Use Spray Tips
The quick–connect on the nozzle extension allows you to
switch between four dierent quick-connect spray tips. Spray
tips can be changed while pressure washer is running once
spray gun trigger safety lock is engaged. The spray tips vary,
following the patterns shown above.
spray tips
Follow these instructions to change spray tips:
1. Pull back collar on quick–connect and pull current spray tip
o. Store spray tips in holder provided on the washer or gun
(location varies by model). Storing nozzles in the designated
holder will help prevent debris from clogging the tip.
2. Select desired spray tip:
• For a gentle rinse, select white 40° spray tip.
• For high-pressure cleaning, select yellow 15° spray tip.
• To scour the surface, select the red 0° spray tip.
• To apply detergent, select black spray tip.
3. Pull back on collar, insert new spray tip and release collar.
Tug on spray tip to ensure it is securely in place.
Usage Tips
• For the most eective cleaning, keep spray tip at least 8 to
24 inches away from cleaning surface.
• If the spray tip comes to close to the surface being cleaned,
it may become damaged. This is especially true if using the red
spray tip.
0
o
RED
40
o
WHITE
soaper
BLACK
15
o
YELLOW
To apply detergent, follow these steps:
1. Review the use of spray tips on the previous page.
2. Prepare detergent solution as required by job. Instructions
can often be found on the detergent bottle.
3. Place small filter end of detergent siphoning tube into
detergent container.
NOTE: Make sure the filter end is fully submerged in detergent
while cleaning.
Please note that only the black spray tip will draw soap. The
Red, Yellow, and White spray tips will not draw soap at all.
using black soap nozzle
4. Ensure the black spray tip is installed.
5. Ensure garden hose is connected to water inlet. Check that
the high pressure hose is connected to spray gun and pump.
Turn water on.
NOTICE
You must attach all hoses before you start the engine.
• Starting the engine without all the hoses connected and
without the water turned ON will damage the pump.
• Damage to equipment resulting from failure to follow this
instruction will void warranty.
6. Start the engine following the instructions in Starting Your
Washer.
7. Apply detergent to surface, using long, even, overlapping
strokes.
8. Allow detergent to “soak in” for 5 minutes before washing
and rinsing. Reapply as needed to prevent surface from drying.
DO NOT allow detergent to dry on as this can damage the
surface.
IMPORTANT: You must flush the detergent siphoning system
after each use by placing the filter into a bucket of clean
water and running the pressure washer at low pressure for 1-2
minutes.
CAUTION
Chemicals can cause bodily injury and/or property damage.
• NEVER use caustic liquid with your pressure washer.
• Use ONLY pressure washer safe detergent/soaps. Follow all
manufacturers instructions
