Specifications
Maximum Input Levels LO gain -14dBu
HI gain -29dBu
Output Level -26dBu when level indicators change to red
Frequency Response 20Hz to 20kHz (+/- 0.5dB)
THD+N Less than 0.03% @ 1kHz, -30dBu input
S/N Ratio 85dB @ 1Khz, -30dBu input
Gain LO +15dB
HI +30dB
Phantom Power Regulated 48 volt power
Current to 14mA (direct short)
Plug-in Power 3.5 volts on all mini-jack mic inputs
Battery Type Built-in 3.7V 2400mAH LiPo
Battery Duration 10 hours typical (no phantom)
Charge Time 4 hours
Dimensions 3.5” x 4” x 2” (L x W x H)
(89 mm x 102 mm x 51 mm)
Weight 14 oz. (0.4 kg)
This device complies with the FCC Rules, Part 15, Class B
