Side XLR Panel
XLR Input
Balanced XLR input to attach professional microphones or
wireless systems. This sends the signal to the Right channel
Side Mini-Jack Panel
OUT
Stereo output jack for connection to the camera
L
Left unbalanced 3.5mm mic input. Provides 3.5 volt plug-in power
R
Right unbalanced 3.5mm mic input. Provides 3.5 volt plug-in power
S
Stereo unbalanced 3.5mm mic input. Provides 3.5 volt plug-in
power
Side XLR Panel
Side Mini-Jack Panel
