Beam E4 - Page 11

Linkage Rod
Linkage Rod
Ball Link (L)
Linkage Rod
Linkage Rod
3-3
Ball Link (L)
Ball Link (S)
Main Blade Holder To Seesaw Mixing Arm
(Linkage Rod, 1.3x10mm)
2 pcs 2 pcs
2 pcs
3 pcs
Washout Arm To Flybar Arm Spacer
(Linkage Rod, 1.3x12mm)
Seesaw Mixing Arm To Swashplate Cap
(Linkage Rod, 1.3x33mm)
Swashplate To Servo Arm
(Linkage Rod, 1.3x25mm)
25
29.2
48.3
40.7
Linkage Rod
Use Ball Link Tool
A
B
C
D
A
B
C
D
A
C
D
B
Ball Link (L),
13.5mm (16 pcs)
Ball Link (S),
11.5mm (2 pcs)
11.5
13.5
11.5 13.5
13.5 13.5
13.5
13.5
13.5
13.5
Flybar Paddle
Main Blade
Swashplate
Make sure the Flybar Paddle,
the Flybar Control Arm and
the Swashplate are level.
Note
Level
Level
Level
(Flybar Contorl Arm)
※
