3
Other Type of Front Panel Connections
For all other type of front panel connections:
Add the parameters of all simple connections that are part of the intended
combined connection.
Ex Approvals
ATEX IECEx
Ex ia IIC T4
(T
a
= -10 … 50 °C)
VTT 08 ATEX 033X
Ex ia IIC T4 Ga
(T
a
= -10 … 50 °C)
IECEx VTT 08.0002X
Special Conditions for Safe Use
Opening MC2-IS voids safety and warranty, if it is valid.
The permissible ambient temperature range is -10 °C ≤ T
a
≤ + 50 °C.
The calibrator shall only be used with rechargeable battery pack type RB-48-
IS.
The battery pack shall not be charged on a hazardous location.
Use only Beamex charger type BC09-IS for charging. The charger shall not
be used in a hazardous location.
The USB connection may be used in safe area only.
The EXT connection shall only be connected with the EXT-s-IS/EXT-IS, ex-
ternal pressure module. However, in safe area, non-IS EXT modules may
also be used.
The calibrator may be used with auxiliary hand held mechanical pressure
calibrator pump type PGM.
The surface of the external pressure module and the calibrator pump contains
light metal, so the user shall be aware of possible impact or friction sparks
when using these auxiliary devices.
The connection cable of the external pressure module as well as the pressure
measurement hose are non-conducting material, so the user shall be aware
of dangers of ignition due to hazardous electrostatic charges.
Due to electrostatic discharge hazard, do not affix any stickers larger than
4 cm
2
(0.62 in
2
) to the calibrator.
0537
II 1 G
